Zetkama Valve

Safety Valve Zetkama

Type : 600

Full lift, angle-type, spring-loaded safety valve with flanged connections, available with closed and open bonnet design

Flanges drilled according to ASME B16.5
Valve design in accordance with ASME Section VIII, ASME Section XIII and API Std 526
Valve marking: UV (ASME Section VIII & XIII), CE (PED), UKCA according to PE(S)R 2016
High tightness level
Bellows design (CrNi and INCONEL)
ATEX version available
suitable for hydrogen and oxygen service

Full Lift Safety Valve Zetkama

Type : 570

Full-lift, angle-type, weight-loaded safety valve with flanged connections, with closed bonnet design.

Flanges drilled in accordance with EN 1092-2 for body material A
Flanges drilled in accordance with EN 1092-1 for body materials F, R
Valve design in compliance with EN ISO 4126-1
High tightness level
High repeatability of operation due to the applied weight-loaded mechanism

Proportional Safety Valve

Type : 240

Proportional angle spring safety valve with flanged ends with a high degree of tightness. The body of the product, depending on the model, may be made of grey cast iron (DN 15-200 for pressure up to 16 bar and max. temperature 300°C),

Flange dimension according to PN EN 1092
Valves made according to PN EN ISO 4126-
Wide range of parameters and DN
High tightness
for valves with soft sealing
Quiet work of valve
Raised tightness of closure
Protection of disc sealing surface in front of limestone
